Product description
Chamber capacity: 10 x GN 1/1 or 10 x 600x400 mm trays.
Inside dimensions of the chamber: 640x452x(H)870 mm .10 sets of rails, 75 mm apart.
Output at chilling to +3° C: 25 kg.
Output at freezing to -18°C: 20 kg.
Weight:120kg.
Technical data
- Height (mm):1535
- Length (mm):790
- Width (mm):900
- Internal length (mm):640
- Internal height (mm):870
- Internal width (mm):452
- Materials:AISI 201 Stainless steel
- Interior material:AISI 201 Stainless steel
- Voltage:230
- Temp range from (°C):-40
- Temp range to (°C):10
- Refrigerant:R290
- Energy label:-
- Climate class:5 (40°C 40% RH)
- Usable volume (L):252
- Capacity value:10
- Capacity unit:Trays
- Noise level (dB):60
- Power (input) (W):1180
- Programmable:Yes
- Probe:Yes
- Machine type:Freestanding
- GN size:GN 1/1
Files to download
Sparepart form 232187 Batch nr 000000 and up. (until 12-2017)
Sparepart form 232187 Batch nr 000000 and up. (from 01-2018)
Declaration of conformity
User manual
