Product description
Chamber capacity: 5 x GN 1/1 or 5 x 600x400 mm trays.
Inside dimensions of the chamber: 640x400x(H)360 mm.
5 sets of rails, 65 mm apart.
Output at chilling to +3° C: 15 kg.
Output at freezing to -18°C: 10 kg.
Weight: 76 kg.
Technical data
- Height (mm):850
- Length (mm):760
- Width (mm):725
- Internal length (mm):640
- Internal height (mm):360
- Internal width (mm):400
- Materials:AISI 201 Stainless steel
- Interior material:AISI 201 Stainless steel
- Number of doors:1
- Voltage:230
- Temp range from (°C):-40
- Temp range to (°C):10
- Refrigerant:R290
- Energy label:-
- Climate class:5 (40°C 40% RH)
- Usable volume (L):94
- Capacity value:5
- Capacity unit:Trays
- Noise level (dB):60
- Power (input) (W):749
- Programmable:Yes
- Probe:Yes
- GN size:GN 1/1
Files to download
Sparepart form 232170 Batch nr 000000 and up. (from 01-2018, until 09-2024)
Declaration of conformity
User manual
